1/2 in. Long Impact Socket 6 PT, Metric

SKU: NS.8LA - Barcode: 3148516551627

HIGH PERFORMANCE - Designed and manufactured for extremely high tightening forces.
IMPACT TOOL - Use with energised tools.
OGV® PROFILE - Maximizing the contact between the socket and nut/bolt to preserves fasteners.
TREATEMENT - Molybdenum chrome steel tempered with heat treatment.
HIGH PROTECTION - Coated with manganese phosphate for higher protection and corrosion resistance.

Full product description

Standards and certifications

This product complies with the following standards and certifications:

DIN 3129, ISO 1711-2, ISO 2725-2, NF ISO 1711-2, NF ISO 2725-2

Click here to learn more about the different standards and certifications.

Warranty

This product is: Lifetime warranty on the tool (replacement)

Click here to learn more about our warranties.

Description

HIGH PERFORMANCE - Designed and manufactured for extremely high tightening forces.
IMPACT TOOL - Use with energised tools.
OGV® PROFILE - Maximizing the contact between the socket and nut/bolt to preserves fasteners.
TREATEMENT - Molybdenum chrome steel tempered with heat treatment.
HIGH PROTECTION - Coated with manganese phosphate for higher protection and corrosion resistance.

Specifications

AttachéNon
Clé à chocsOui
ExtensibleNon
FinitionPhosphate
FlexibleNon
Isolation 1000VNon
Longueur du produit78 mm
MagnétiqueNon
Pour visseuse à chocNon
Poids net130 g
Taille de la douille24 mm
Type de douilleLong

Technical drawing and dimensions

		A (mm)	D1 (mm)	L1 (mm)	L (mm)
NS.8LA	[NS.8LA] 1/2" long impact socket 6-point, 8 mm	8.00	15.00	21.00	78.00
NS.10LA	[NS.10LA] 1/2 in. Long Impact Socket, 6-point, 10 mm	12.00	17.00	21.00	78.00
NS.11LA	[NS.11LA] 1/2 in. Long Impact Socket, 6-point, 11 mm	11.00	18.00	21.00	78.00
NS.12LA	[NS.12LA] 1/2 in. Long Impact Socket, 6-point, 12 mm	12.00	20.00	21.00	78.00
NS.13LA	[NS.13LA] 1/2 in. Long Impact Socket, 6-point, 13 mm	13.00	21.00	21.00	78.00
NS.14LA	[NS.14LA] 1/2" long impact socket 6-point, 14 mm	14.00	22.00	21.00	78.00
NS.16LA	[NS.16LA] 1/2 in. Long Impact Socket, 6-point, 16 mm	16.00	24.00	21.00	78.00
NS.17LA	[NS.17LA] 1/2" long impact socket 6-point, 17 mm	17.00	26.00	21.00	78.00
NS.18LA	[NS.18LA] 1/2 in. Drive 18mm 6-Point Long Impact Socket	18.00	28.00	21.00	78.00
NS.19LA	[NS.19LA] 1/2" long impact socket 6-point, 19 mm	19.00	28.00	21.00	78.00
NS.21LA	[NS.21LA] 1/2" long impact socket 6-point, 21 mm	21.00	30.00	21.00	78.00
NS.22LA	[NS.22LA] 1/2 in. Long Impact Socket 6-points, 22 mm	22.00	32.00	26.00	78.00
NS.23LA	[NS.23LA] 1/2" long impact socket 6-point, 23 mm	23.00	34.00	26.00	78.00
NS.24LA	[NS.24LA] 1/2 in. Long Impact Socket, 6-point, 24 mm	24.00	34.00	26.00	78.00
NS.26LA	[NS.26LA] 1/2" long impact socket 6-point, 26 mm	26.00	36.00	26.00	78.00
NS.27LA	[NS.27LA] 1/2" long impact socket 6-point, 27 mm	27.00	38.00	26.00	78.00
NS.28LA	[NS.28LA] 1/2 in. Long Impact Socket, 6-point, 28 mm	28.00	40.00	26.00	78.00
NS.29LA	[NS.29LA] 1/2 in. Long Impact Socket, 6-point, 29 mm	29.00	40.00	26.00	78.00
NS.30LA	[NS.30LA] 1/2" long impact socket 6-point, 30 mm	30.00	42.00	26.00	78.00
NS.32LA	[NS.32LA] 1/2 in. Long Impact Socket, 6-point, 32 mm	32.00	44.00	26.00	78.00
