1/4 in. Long-Reach 12 PT Sockets

SKU: R.4EL  -  Barcode: 3148519387100
  • HIGH PERFORMANCE - Designed and manufactured for extremely high tightening forces.
  • OGV® PROFILE - Maximizing the contact between the socket and nut/bolt to preserves fasteners.
  • NECK-DOWN DESIGN - Facilitating the use in narrow spaces.
  • FINISHING - Bright chrome.
  • ACCESSIBILITY - Long shape which offers better accessibility in deep spaces.
Full product description
Reference comparison

Standards and certifications

This product complies with the following standards and certifications:

ISO 1711-1, ISO 2725-1, NF ISO 1711-1, NF ISO 2725-1

Click here to learn more about the different standards and certifications.

Warranty

This product is: Lifetime warranty on the tool (replacement)

Click here to learn more about our warranties.

Description
  • HIGH PERFORMANCE - Designed and manufactured for extremely high tightening forces.
  • OGV® PROFILE - Maximizing the contact between the socket and nut/bolt to preserves fasteners.
  • NECK-DOWN DESIGN - Facilitating the use in narrow spaces.
  • FINISHING - Bright chrome.
  • ACCESSIBILITY - Long shape which offers better accessibility in deep spaces.

Specifications
  • AntidéflagrantNon
  • AttachéNon
  • Clé à chocsNon
  • Diamètre6.7 mm
  • FinitionVernis chromé
  • Isolation 1000VNon
  • Longueur du produit50 mm
  • Pour visseuse à chocNon
  • Poids net18 g
  • Taille de la douille4 mm
  • Type de douilleLong

Technical drawing and dimensions

A (mm)D1 (mm)L1 (mm)L (mm)
R.4EL [R.4EL] 1/4 in. Long Socket 12-point, 4 mm 4.0011.204.0050.00
R.5.5EL [R.5.5EL] 1/4 in. Drive 12-Point Long-Reach Socket 5.5011.206.0050.00
R.5EL [R.5EL] 1/4 in. Long Socket, 12-point, 5 mm 5.0011.205.5050.00
R.6EL [R.6EL] 1/4 in. Long Socket 12-points, 6 mm 6.0011.207.0050.00
R.7EL [R.7EL] 1/4 in. Long Socket, 12-point, 7 mm 7.0011.208.0050.00
R.8EL [R.8EL] 1/4 in. Long Socket, 12-point, 8 mm 8.0011.709.0050.00
R.9EL [R.9EL] 1/4" long socket 12-point, 9 mm 9.0012.0010.0050.00
R.10EL [R.10EL] 1/4 in. Long Socket, 12-point, 10 mm 10.0012.9011.0050.00
R.11EL [R.11EL] 1/4 in. Long Socket, 12-point, 11 mm 11.0014.3012.0050.00
R.12EL [R.12EL] 1/4" long socket 12-point, 12 mm 12.0015.5013.0050.00
R.13EL [R.13EL] 1/4 in. Long Socket 12-point, 13 mm 13.0016.4014.0050.00
R.14EL [R.14EL] 1/4" long socket 12-point, 14 mm 14.0017.9016.0050.00

Documents

1/4 in. Long-Reach 12 PT Sockets

References available

  • [R.4EL] 1/4 in. Long Socket 12-point, 4 mm
  • [R.5.5EL] 1/4 in. Drive 12-Point Long-Reach Socket
  • [R.5EL] 1/4 in. Long Socket, 12-point, 5 mm
  • [R.6EL] 1/4 in. Long Socket 12-points, 6 mm
  • [R.7EL] 1/4 in. Long Socket, 12-point, 7 mm
  • [R.8EL] 1/4 in. Long Socket, 12-point, 8 mm
  • [R.9EL] 1/4" long socket 12-point, 9 mm
  • [R.10EL] 1/4 in. Long Socket, 12-point, 10 mm
  • [R.11EL] 1/4 in. Long Socket, 12-point, 11 mm
  • [R.12EL] 1/4" long socket 12-point, 12 mm
  • [R.13EL] 1/4 in. Long Socket 12-point, 13 mm
  • [R.14EL] 1/4" long socket 12-point, 14 mm

Lieu de fabrication

N/A

Normes & certifications

ISO 1711-1, ISO 2725-1, NF ISO 1711-1, NF ISO 2725-1

Période de garantie

Lifetime warranty on the tool (replacement)
