22 - 15° Midget Double Open-End Wrenches

SKU: 22.3.2X5.5  -  Barcode: 3148510947006
  • ACCESSIBILITY - Short shank and slim heads for manoeuvrability in confined spaces.
  • OFFSET - Heads hinged at 15°.
  • SMALL DIMENSIONS - Metric sizes: 3.2 to 13 mm.
  • DOUBLE DIMENSIONS - 2 size per wrench.
Full product description
Reference comparison

Standards and certifications

This product complies with the following standards and certifications:

ISO 3318, ISO 691, NF ISO 3318, NF ISO 691

Click here to learn more about the different standards and certifications.

Warranty

This product is: Lifetime warranty on the tool (replacement)

Click here to learn more about our warranties.

Description
  • ACCESSIBILITY - Short shank and slim heads for manoeuvrability in confined spaces.
  • OFFSET - Heads hinged at 15°.
  • SMALL DIMENSIONS - Metric sizes: 3.2 to 13 mm.
  • DOUBLE DIMENSIONS - 2 size per wrench.

Specifications
  • Anneau d'arrêtNon
  • AntidéflagrantNon
  • AttachéNon
  • FinitionChrome satin
  • Isolation 1000VNon
  • Longueur du produit70 mm
  • Poids net impérial0.01 lbs
  • Poids net0.01 Kg
  • Type de longueurCourt
  • Unité de mesureMétrique

Technical drawing and dimensions

A (mm)B1 (mm)B (mm)E (mm)L (mm)
22.3.2X5.5 [22.3.2X5.5] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 3.2X5.5 mm 13.0010.002.4070.00
22.3.2X5.5PB [22.3.2X5.5PB] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 3.2X5.5 mm 13.0010.002.4070.00
22.4X5 [22.4X5] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 4X5 mm 4 x 513.0010.002.4070.00
22.4X5PB [22.4X5PB] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 4X5 mm 4x5013.0010.002.4070.00
22.6X7 [22.6X7] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 6X7 mm 6 x 716.0014.002.7080.00
22.8X9 [22.8X9] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 8X9 mm 8 x 920.0018.003.0090.00
22.10X11 [22.10X11] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 10X11 mm 10 x 1123.0021.003.00100.00
22.12X13 [22.12X13] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 12X13 mm 12 x 1328.0026.003.50110.00

Documents

22 - 15° Midget Double Open-End Wrenches

References available

  • [22.3.2X5.5] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 3.2X5.5 mm
  • [22.3.2X5.5PB] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 3.2X5.5 mm
  • [22.4X5] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 4X5 mm
  • [22.4X5PB] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 4X5 mm
  • [22.6X7] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 6X7 mm
  • [22.8X9] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 8X9 mm
  • [22.10X11] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 10X11 mm
  • [22.12X13] DOUBLE OPEN END WRENCH - 22 - Midget - Slim Head - 12X13 mm

Lieu de fabrication

N/A

Normes & certifications

ISO 3318, ISO 691, NF ISO 3318, NF ISO 691

Période de garantie

Lifetime warranty on the tool (replacement)
