271A - Compact G-clamp

SKU: 271A.40 - Barcode: 3148511626016

Clamp capacity 100mm.
Galvanised body with burnished screw and control bar.
Throat depth 77mm.

Full product description

References available Reference comparison

Product variants

Warranty

This product is: Lifetime warranty on the tool (replacement)

Click here to learn more about our warranties.

Description

Clamp capacity 100mm.
Galvanised body with burnished screw and control bar.
Throat depth 77mm.

Specifications

Arrêt de sécuritéNon
Capacité de serrage40 mm
Distance entre les centres des trous de fixation42 mm
Épaisseur de la tige42 mm
Hauteur du produit75 mm
Longueur de la tige75 mm
Longueur du produit100 mm
Matériau du corpsZinc moulé
Matériau de la poignéeZinc moulé
Matériau visN/A
Nombre de pièces1
Ouverture maximale de la mâchoire40 mm
Poids net0.3 Kg
Type de produit pinces et étauxÉtaux
Type de patin de la mâchoireRéparer

Technical drawing and dimensions

			A max (mm)	L1 (mm)	L2 (mm)	L (mm)
	271A.40	[271A.40] 40mm Compact G-Clamp	40.00	75.00	42.00	100.00
	271A.60	[271A.60] 60mm Compact G-Clamp	60.00	98.00	57.00	130.00
	271A.80	[271A.80] 80mm Compact G-Clamp	80.00	115.00	67.00	167.00
	271A.100	[271A.100] 100mm Compact G-Clamp	1000	131.00	77.00	1920
	271A.150	[271A.150] 150mm Compact G-clamp	150.00	162.00	98.00	262.00
	271A.200	[271A.200] Compact G-clamp, 200 mm	2000	185.00	108.00	3200
	271A.250	[271A.250] 250mm Compact G-Clamp	2500	202.00	118.00	3800

Documents

271A - Compact G-clamp

References available

[271A.40] 40mm Compact G-Clamp
[271A.60] 60mm Compact G-Clamp
[271A.80] 80mm Compact G-Clamp
[271A.100] 100mm Compact G-Clamp
[271A.150] 150mm Compact G-clamp
[271A.200] Compact G-clamp, 200 mm
[271A.250] 250mm Compact G-Clamp

Lieu de fabrication

N/A

Normes & certifications

N/A

Période de garantie

Lifetime warranty on the tool (replacement)
