3/4" Impact sockets - Metric
SKU:
E041102
3/4" Impact sockets - Metric - [E041102] EXPERT by FACOM® 3/4 in. Impact socket, Metric 19 mm is backordered and will ship as soon as it is back in stock.
Standards and certifications
Standards and certifications
This product complies with the following standards and certifications:
ISO 1711-2, ISO 2725-2, ISO 691
Click here to learn more about the different standards and certifications.
Warranty
Warranty
This product is: This product is covered by the statutory warranty
Click here to learn more about our warranties.
Description
Description
Specifications
Specifications
- Longueur du produit38 mm
- Poids net0.367 Kg
Technical drawing and dimensions
Technical drawing and dimensions
| A (mm) | D1 (mm) | D2 (mm) | L (mm) | |||
|---|---|---|---|---|---|---|
| E041102 | [E041102] EXPERT by FACOM® 3/4 in. Impact socket, Metric 19 mm | 19.00 | 30.00 | 28.70 | 38.00 | |
| E041103 | [E041103] EXPERT by FACOM® 3/4 in. Impact socket, Metric 21 mm | 21.00 | 30.00 | 38.00 | ||
| E041104 | [E041104] EXPERT by FACOM® 3/4 in. Impact Socket, Metric 22 mm | 22.00 | 30.00 | 38.00 | ||
| E041106 | [E041106] EXPERT by FACOM® 3/4 in. Impact Socket, Metric 27 mm | 27.00 | 30.00 | 50.00 | ||
| E113468 | [E113468] EXPERT by FACOM® 3/4 in. Impact socket, Metric 28 mm | 28.00 | 30.00 | 50.00 | ||
| E113469 | [E113469] EXPERT by FACOM® 3/4 in. Impact Socket, 29 mm | 29.00 | 44.00 | 54.00 | ||
| E113470 | [E113470] EXPERT by FACOM® 3/4 in. Impact Socket, Metric 30 mm | 30.00 | 30.00 | 50.00 | ||
| E113471 | [E113471] EXPERT by FACOM® 3/4 in. Impact socket, Metric 32 mm | 32.00 | 44.00 | 50.00 | ||
| E113472 | [E113472] EXPERT by FACOM® 3/4 in. Impact socket, Metric 33 mm | 33.00 | 44.00 | 56.00 | ||
| E113473 | [E113473] EXPERT by FACOM® 3/4 in. Impact Socket, Metric 34 mm | 34.00 | 44.00 | 56.00 | ||
| E113474 | [E113474] EXPERT by FACOM® 3/4 in. Impact socket, 35 mm | 35.00 | 44.00 | 56.00 | ||
| E113475 | [E113475] EXPERT by FACOM® 3/4 in. Impact socket, Metric 36 mm | 36.00 | 44.00 | 56.00 | ||
| E113476 | [E113476] EXPERT by FACOM® 3/4 in. Impact Socket, 38 mm | 38.00 | 44.00 | 58.00 | ||
| E113477 | [E113477] EXPERT by FACOM® 3/4 in. Impact socket, Metric 41 mm | 41.00 | 44.00 | 58.00 | ||
| E113478 | [E113478] EXPERT by FACOM® 3/4 in. Impact Socket, Metric 42 mm | 42.00 | 44.00 | 58.00 | ||
| E113479 | [E113479] EXPERT by FACOM® 3/4 in. Impact socket, Metric 46 mm | 46.00 | 44.00 | 63.00 |
