Facom - The Art of Precision since 1918.

31 - Extra slim double open-end wrenches, metric

SKU: 31.6X7  -  Barcode: 3148510969985
  • THIN DESGIN - 30 % slimmer than a classical open end wrench.
  • MAXIMUM ACCESSIBILITY - Indispensable for confined access and locknuts.
  • OFFSET - Heads hinged at 15°.
  • DIMENSIONS - Metric sizes: 6 to 24 mm.
  • DOUBLE DIMENSIONS - 2 size per wrench.
Full product description
Reference comparison

Standards and certifications

This product complies with the following standards and certifications:

ISO 3318, ISO 691, NF ISO 3318, NF ISO 691

Click here to learn more about the different standards and certifications.

Warranty

This product is: Lifetime warranty on the tool (replacement)

Click here to learn more about our warranties.

Description
  • THIN DESGIN - 30 % slimmer than a classical open end wrench.
  • MAXIMUM ACCESSIBILITY - Indispensable for confined access and locknuts.
  • OFFSET - Heads hinged at 15°.
  • DIMENSIONS - Metric sizes: 6 to 24 mm.
  • DOUBLE DIMENSIONS - 2 size per wrench.

Specifications
  • Anneau d'arrêtNon
  • AntidéflagrantNon
  • AttachéNon
  • FinitionChrome satin
  • Isolation 1000VNon
  • Longueur du produit148 mm
  • Poids net0.02 Kg
  • Type de longueurMince

Technical drawing and dimensions

A (mm)B1 (mm)B (mm)E (mm)L (mm)
31.6X7 [31.6X7] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 6X7 mm 6 x 719.6016.602.20148.00
31.8X9 [31.8X9] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 8X9 mm 8 x 924.5020.502.60175.00
31.10X11 [31.10X11] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 10X11 mm 10 x 1124.5020.502.60175.00
31.12X13 [31.12X13] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 12X13 mm 12 x 1333.5029.003.60210.00
31.14X15 [31.14X15] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 14X15 mm 14 x 1533.5029.003.60210.00
31.16X17 [31.16X17] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 16X17 mm 16 x 1742.5038.004.60250.00
31.18X19 [31.18X19] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 18X19 mm 18 x 1942.5038.004.60
31.22X24 [31.22X24] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 22X24 mm 22 x 2452.0048.005.60

Documents

31 - Extra slim double open-end wrenches, metric

References available

  • [31.6X7] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 6X7 mm
  • [31.8X9] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 8X9 mm
  • [31.10X11] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 10X11 mm
  • [31.12X13] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 12X13 mm
  • [31.14X15] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 14X15 mm
  • [31.16X17] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 16X17 mm
  • [31.18X19] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 18X19 mm
  • [31.22X24] DOUBLE OPEN END WRENCH - 31 - Extra Slim - Satin Chrome Finish - 22X24 mm

Lieu de fabrication

N/A

Normes & certifications

ISO 3318, ISO 691, NF ISO 3318, NF ISO 691

Période de garantie

Lifetime warranty on the tool (replacement)
View product
