Facom - The Art of Precision since 1918.

440.SLS - Combination Wrenches, Inch - SLS solution

SKU: 440.1PSLS  -  Barcode: 3662424028847
  • Tool equipped with a FACOM SLS attachment solution, preventing any risk of accidental falls.
  • The crimped "sliding" cable solution, selected and tested by FACOM, maintains user ergonomics.
  • Standard wrench for all current applications.
  • High mechanical strength combined with compact size meeting aeronautical standards.
  • Ring head: - Ring open end (size E) designed for better access to series or embedded screws. - OGV® profile with 12-point ring for powerful tightening while protecting the nut. - Ring head angled at 15°.
  • Open end head: - Open end angled at 15°. - Open end head-handle geometry optimised for increased access.
  • Inches sizes: 1/2".
  • Presentation: satin chrome finish.
Full product description
Reference comparison

Standards and certifications

This product complies with the following standards and certifications:

ASME B107.100

Click here to learn more about the different standards and certifications.

Warranty

This product is: This product is covered by a 2-year warranty

Click here to learn more about our warranties.

Description
  • Tool equipped with a FACOM SLS attachment solution, preventing any risk of accidental falls.
  • The crimped "sliding" cable solution, selected and tested by FACOM, maintains user ergonomics.
  • Standard wrench for all current applications.
  • High mechanical strength combined with compact size meeting aeronautical standards.
  • Ring head: - Ring open end (size E) designed for better access to series or embedded screws. - OGV® profile with 12-point ring for powerful tightening while protecting the nut. - Ring head angled at 15°.
  • Open end head: - Open end angled at 15°. - Open end head-handle geometry optimised for increased access.
  • Inches sizes: 1/2".
  • Presentation: satin chrome finish.

Specifications
  • Hauteur du produit53 mm
  • Longueur du produit274 mm
  • Marquage CEOui
  • Nombre de pièces1
  • Poids net0.34 Kg

Technical drawing and dimensions

A (mm)B1 (mm)B (mm)E1 (mm)E2 (mm)E (mm)L (mm)
440.1PSLS [440.1PSLS] 1 in. Combination Wrench, Safety Lock System 1.0036.4053.0014.709.909.40274.00
440.1/2SLS [440.1/2SLS] 1/2 in. Combination Wrench, Safety Lock System 19.3028.708.606.104.80170.00
440.1/4SLS [440.1/4SLS] 1/4 in. Combination Wrench, Safety Lock System 10.0014.106.003.803.10115.00
440.11/16SLS [440.11/16SLS] 11/16 in. Combination Wrench, Safety Lock System 25.3037.0010.907.606.50202.00
440.11/32SLS [440.11/32SLS] 11/32 in. Combination Wrenc, Safety Lock System 14.2021.207.104.703.90138.00
440.13/16SLS [440.13/16SLS] 13/16 in. Combination Wrench With Safety Lock System 29.5043.1012.308.606.30224.00
440.15/16SLS [440.15/16SLS] Combination wrench inch 15/16" Safety Lock System 35.0051.0014.209.708.90267.00
440.1P1/16SLS [440.1P1/16SLS] Combination wrench inch 1'1/16" Safety Lock System 39.2058.0015.6010.408.90295.00
440.1P1/4SLS [440.1P1/4SLS] 1-1/4 in. Combination Wrench, Safety Lock System 46.1068.0018.0012.5011.50355.00
440.1P1/8SLS [440.1P1/8SLS] 1-1/8 in. Combination Wrench, Safety Lock System 40.6060.7016.1010.7010.60305.00
440.1P5/16SLS [440.1P5/16SLS] 1-5/16 in. Combination Wrench, Safety Lock System 47.0069.8018.5012.8011.80380.00
440.3/4SLS [440.3/4SLS] Combination wrench inch 3/4" Safety Lock System 27.8041.2011.908.307.20216.00
440.3/8SLS [440.3/8SLS] Combination wrench inch 3/8" Safety Lock System 15.0023.007.605.204.20145.00
440.5/16SLS [440.5/16SLS] 5/16 in.Combination Wrench, Safety Lock System 12.8019.206.704.703.50133.00
440.5/8SLS [440.5/8SLS] 5/8 in. Combination Wrench, Safety Lock System 23.9035.6010.507.306.40195.00
440.7/16SLS [440.7/16SLS] 7/16 in. Combination Wrench, Safety Lock System 16.9024.508.105.504.60155.00
440.7/8SLS [440.7/8SLS] 7/8 in. Combination Wrench, Safety Lock System 32.3046.9013.309.008.30248.00
440.9/16SLS [440.9/16SLS] 9/16 in.Combination Wrench, Safety Lock System 21.1031.009.506.405.70180.00

Documents

440.SLS - Combination Wrenches, Inch - SLS solution

References available

  • [440.1PSLS] 1 in. Combination Wrench, Safety Lock System
  • [440.1/2SLS] 1/2 in. Combination Wrench, Safety Lock System
  • [440.1/4SLS] 1/4 in. Combination Wrench, Safety Lock System
  • [440.11/16SLS] 11/16 in. Combination Wrench, Safety Lock System
  • [440.11/32SLS] 11/32 in. Combination Wrenc, Safety Lock System
  • [440.13/16SLS] 13/16 in. Combination Wrench With Safety Lock System
  • [440.15/16SLS] Combination wrench inch 15/16" Safety Lock System
  • [440.1P1/16SLS] Combination wrench inch 1'1/16" Safety Lock System
  • [440.1P1/4SLS] 1-1/4 in. Combination Wrench, Safety Lock System
  • [440.1P1/8SLS] 1-1/8 in. Combination Wrench, Safety Lock System
  • [440.1P5/16SLS] 1-5/16 in. Combination Wrench, Safety Lock System
  • [440.3/4SLS] Combination wrench inch 3/4" Safety Lock System
  • [440.3/8SLS] Combination wrench inch 3/8" Safety Lock System
  • [440.5/16SLS] 5/16 in.Combination Wrench, Safety Lock System
  • [440.5/8SLS] 5/8 in. Combination Wrench, Safety Lock System
  • [440.7/16SLS] 7/16 in. Combination Wrench, Safety Lock System
  • [440.7/8SLS] 7/8 in. Combination Wrench, Safety Lock System
  • [440.9/16SLS] 9/16 in.Combination Wrench, Safety Lock System

Lieu de fabrication

N/A

Normes & certifications

ASME B107.100

Période de garantie

This product is covered by a 2-year warranty
