64C - 4-in-1 double box-end ratchet wrenches, metric
64C - 4-in-1 double box-end ratchet wrenches, metric - [64C.S1] STRAIGHT RATCHET RING WRENCH - 64C.S - 4 Sizes - 5° Arc Swing - 8X10-12X13 mm is backordered and will ship as soon as it is back in stock.
Standards and certifications
Standards and certifications
This product complies with the following standards and certifications:
ASME B107.100, DIN ISO 1711-1, ISO 1711-1, ISO 691, NF ISO 1711-1
Click here to learn more about the different standards and certifications.
Warranty
Warranty
This product is: Lifetime warranty on the tool (replacement)
Click here to learn more about our warranties.
Description
Description
Specifications
Specifications
- Angle de reprise5 deg
- Anneau d'arrêtNon
- AntidéflagrantNon
- AttachéNon
- FinitionChrome satin
- Isolation 1000VNon
- InversionLevier
- Longueur du produit150 mm
- Nombre de dents72
- Poids net0.105 Kg
- Tête flexibleNon
Technical drawing and dimensions
Technical drawing and dimensions
| A (mm) | B1 (mm) | B (mm) | L (mm) | |||
|---|---|---|---|---|---|---|
| 64C.S1 | [64C.S1] STRAIGHT RATCHET RING WRENCH - 64C.S - 4 Sizes - 5° Arc Swing - 8X10-12X13 mm | 8 x 10 - 12 x 13 | 25.20 | 20.20 | 150.00 | |
| 64C.S2 | [64C.S2] STRAIGHT RATCHET RING WRENCH - 64C.S - 4 Sizes - 5° Arc Swing - 16X17-18X19 mm | 16 x 17 - 18 x 19 | 34.00 | 31.80 | 230.00 | |
| 64C.S3 | [64C.S3] STRAIGHT RATCHET RING WRENCH - 64C.S - 4 Sizes - 5° Arc Swing - 12X14-13X15 mm | 12 x 14 - 13 x 15 | 29.50 | 26.50 | 190.00 |
