83H - Long Hexagonal Keys, Metric
83H - Long Hexagonal Keys, Metric - [83H.2] 2mm Long Metric Keys is backordered and will ship as soon as it is back in stock.
Made in France
Made in France
This product is Made in France in our factories.
Click here to learn more about Our Factories.
Standards and certifications
Standards and certifications
This product complies with the following standards and certifications:
ASME B18.3.2M, DIN ISO 2936, ISO 2936, NF ISO 2936
Click here to learn more about the different standards and certifications.
Warranty
Warranty
This product is: Lifetime warranty on the tool (replacement)
Click here to learn more about our warranties.
Description
Description
Specifications
Specifications
- Finition du produitPhosphate noir
- Hauteur du produit16 mm
- Inclinaison tête sphérique90°
- Largeur de la tête2
- Longueur du produit75 mm
- Marquage CEOui
- Nombre de pièces1
- Poids net0.002 Kg
- Type de têteFixe
- Type de clé hexagonaleClés hexagonales longues - en L
Technical drawing and dimensions
Technical drawing and dimensions
| A (mm) | H (mm) | L (mm) | |||
|---|---|---|---|---|---|
| 83H.2 | [83H.2] 2mm Long Metric Keys | 2.00 | 16.00 | 75.00 | |
| 83H.2PB | [83H.2PB] 2mm Long Metric Key | 2.00 | 16.00 | 75.00 | |
| 83H.3 | [83H.3] Long metric keys, 3 mm | 3.00 | 20.00 | 90.00 | |
| 83H.3PB | [83H.3PB] 3mm Long Metric Keys | 3.00 | 20.00 | 90.00 | |
| 83H.4 | [83H.4] Long metric keys, 4 mm | 4.00 | 25.00 | 100.00 | |
| 83H.4PB | [83H.4PB] 4mm Long Metric Key With Spherical Head | 4.00 | 25.00 | 100.00 | |
| 83H.1.5 | [83H.1.5] Long metric keys, 1.5 mm | 1.50 | 14.00 | 62.00 | |
| 83H.1.5PB | [83H.1.5PB] Long metric keys, 1.5 mm | 1.50 | 14.00 | 62.00 | |
| 83H.2.5 | [83H.2.5] 2.5mm Long Metric Key | 2.50 | 18.00 | 85.00 | |
| 83H.2.5PB | [83H.2.5PB] Long metric keys, 2.5 mm | 2.50 | 18.00 | 85.00 | |
| 83H.3.5 | [83H.3.5] 3.5mm Long Metric Key | 3.50 | 25.00 | 95.00 | |
| 83H.4.5 | [83H.4.5] Long metric keys, 4.5 mm | 4.50 | 26.00 | 110.00 | |
| 83H.5 | [83H.5] 5mm Long Metric Key | 5.00 | 28.00 | 115.00 | |
| 83H.5PB | [83H.5PB] 5 mm Long Metric Keys | 5.00 | 28.00 | 115.00 | |
| 83H.6 | [83H.6] 6mm Long Metric Key | 6.00 | 32.00 | 135.00 | |
| 83H.6PB | [83H.6PB] 6mm Long Metric Key | 6.00 | 32.00 | 135.00 | |
| 83H.7 | [83H.7] 7mm Long Key | 7.00 | 34.00 | 140.00 | |
| 83H.7PB | [83H.7PB] 7mm Long Metric Key | 7.00 | 34.00 | 140.00 | |
| 83H.8 | [83H.8] Long metric keys, 8 mm | 8.00 | 36.00 | 150.00 | |
| 83H.8PB | [83H.8PB] Long metric keys, 8 mm | 8.00 | 36.00 | 150.00 | |
| 83H.9 | [83H.9] 9mm Long Metric Key | 9.00 | 38.00 | 160.00 | |
| 83H.9PB | [83H.9PB] Long metric keys, 9 mm | 9.00 | 38.00 | 160.00 | |
| 83H.10PB | [83H.10PB] 10mm Long Metric Key | 10.00 | 40.00 | 170.00 | |
| 83H.11 | [83H.11] 11mm Long Metric Key | 11.00 | 42.00 | 180.00 | |
| 83H.11PB | [83H.11PB] 11mm Long Metric Key | 11.00 | 42.00 | 180.00 | |
| 83H.12 | [83H.12] Long metric keys, 12 mm | 12.00 | 45.00 | 190.00 | |
| 83H.12PB | [83H.12PB] 12 mm Long Metric Key | 12.00 | 45.00 | 190.00 | |
| 83H.13 | [83H.13] Long metric keys, 13 mm | 13.00 | 50.00 | 200.00 | |
| 83H.13PB | [83H.13PB] 13mm Long Metric Keys | 13.00 | 50.00 | 200.00 | |
| 83H.14 | [83H.14] 14mm Long Metric Key | 14.00 | 56.00 | 215.00 | |
| 83H.14PB | [83H.14PB] Long metric keys, 14 mm | 14.00 | 56.00 | 215.00 | |
| 83H.15 | [83H.15] Long metric keys, 15 mm | 15.00 | 58.00 | 225.00 | |
| 83H.16 | [83H.16] 16mm Long Metric Key | 16.00 | 60.00 | 235.00 | |
| 83H.17 | [83H.17] 17mm Long Key | 17.00 | 63.00 | 245.00 | |
| 83H.18 | [83H.18] Long metric keys, 18 mm | 18.00 | 66.00 | 255.00 | |
| 83H.19 | [83H.19] Long metric keys, 19 mm | 19.00 | 70.00 | 265.00 | |
| 83H.22 | [83H.22] 22mm Long Metric Key | 22.00 | 80.00 | 275.00 | |
| 83H.23 | [83H.23] 23mm Long Metric Key | 23.00 | 85.00 | 285.00 | |
| 83H.24 | [83H.24] Long metric keys, 24 mm | 24.00 | 90.00 | 299.00 | |
| 83H.27 | [83H.27] 27mm Long Key | 27.00 | 100.00 | 315.00 | |
| 83H.32 | [83H.32] Long metric keys, 32 mm | 32.00 | 125.00 | 64.00 |
