Standard" cutter
SKU:
996.8
- Blade inserts in high-performance steel.
- Compact and powerful with ergonomic grips.
- Capacity: - 8 mm for 60 - 100 kg/mm² soft steel cable. - 7 mm for 130 - 160 kg/mm² hard steel cable. - 6 mm for 60 kg/mm² round cable.
- Spare blades: 996.L8.
Standards and certifications
Standards and certifications
This product complies with the following standards and certifications:
75-002, ASME B107.500, NFE 75-001
Click here to learn more about the different standards and certifications.
Warranty
Warranty
This product is: Lifetime warranty on the tool (replacement)
Click here to learn more about our warranties.
Description
Description
- Blade inserts in high-performance steel.
- Compact and powerful with ergonomic grips.
- Capacity: - 8 mm for 60 - 100 kg/mm² soft steel cable. - 7 mm for 130 - 160 kg/mm² hard steel cable. - 6 mm for 60 kg/mm² round cable.
- Spare blades: 996.L8.
Specifications
Specifications
- GripPoignée ergonomique
- Hauteur du produit21 mm
- Longueur du ruban21 mm
- Largeur de la tête42
- Longueur du produit340 mm
- Matériau de la lameAcier
- Mâchoire crantéeOui
- Nombre de pièces1
- Poids net1 Kg
- Type de coupeRapide
- Type de coupeCoupe par poussée
- Type de mâchoireStandard
- Type de poignéePlastique
- VDE 1000 VOui
Technical drawing and dimensions
Technical drawing and dimensions
-
A (mm)12.00
-
B (mm)42.00
-
E (mm)16.00
-
L1 (mm)21.00
-
L2 (mm)115 - 470
-
L (mm)340.00
