DF - Analogic Brake Bleeder

SKU: DF.81 - Barcode: 3662424080661

Tank 10L.
Accessory storage.
Connects to the vehicle's 12 V battery.
'High volume' 1.5 litre /min pump (open circuit. allowing fast brake fluid renewal.
Pressure adjusted by button.
Automatic low level stop gauge.
Regulated pressure adjustable from 0.5 to 4 bar with Glycerine pressure gauge.
Low DOT fluid level with automatic stop.
Lateral hose storage tab.
Certificate of compliance issued at end of manufacturing (individual check).

Full product description

References available Reference comparison

Product variants

Standards and certifications

This product complies with the following standards and certifications:

2011/65/EU (RoHS), 2012/19/EU (WEEE), 2014/30/EU (EMC)

Click here to learn more about the different standards and certifications.

Warranty

This product is: This product is covered by a 2-year warranty

Click here to learn more about our warranties.

Description

Tank 10L.
Accessory storage.
Connects to the vehicle's 12 V battery.
'High volume' 1.5 litre /min pump (open circuit. allowing fast brake fluid renewal.
Pressure adjusted by button.
Automatic low level stop gauge.
Regulated pressure adjustable from 0.5 to 4 bar with Glycerine pressure gauge.
Low DOT fluid level with automatic stop.
Lateral hose storage tab.
Certificate of compliance issued at end of manufacturing (individual check).

Specifications

Compatible avec remplissage automatiqueNon
Dépressurisation automatiqueNon
Indicateur automatique d’arrêt de niveau basNon
MatériauPlastique
ModuleNon
Nombre de pièces1
Pour purger les embrayages de poids lourdsOui
Peut être utilisé sur véhicule légerOui
Peut être utilisé sur motoOui
Poids net16.2 Kg
Support magnétique inclusNon

Spare parts

CAP SA - DF.20-07
VALVES & SEALS KIT - DF.20-07-01
BOTTLE - DF.20-11
BRACKET - DF.UNI-G
PCB SA - REP-DF.80-C
SWITCH - REP-DF.80-G
REGULATOR - REP-DF.81-A
PANEL FRONT - REP-DF.81-B
PIPE SA - REP-DF.81-D
VALVE - REP-DF.81-E
PRESSURE GAUGE - REP-DF.81-F
PCB SA - REP-DF.81-G
PANEL FRONT - REP-DF.81-H
KIT - REP-DF.81-J
PANEL - REP-DF.81-M
TUBE - REP-DF.81-N
TUBE - REP-DF.81-Q
TUBE - REP-DF.81-R
TUBE - REP-DF.81-S
TUBE - REP-DF.81-T
TUBE - REP-DF.81-U
WIRE HARNESS - REP-DF.UNI-A
WHEEL SET - REP-DF.UNI-C
SCREW TORX - REP-DF.UNI-H
SCREW TORX - REP-DF.UNI-I
FRAME - REP-DF.UNI-J
CAP - REP-DF.UNI-L
CABLE - REP-DF.UNI-M
HOSE SA - REP-DF.UNI-P
TUBE - REP-DF.UNI-Q
TUBE - REP-DF.UNI-R
PUMP - REP-DF.UNI-T

Documents

User Guide
