EXPERT by FACOM® 6 x 6 point Flare Nut Wrenches
SKU:
E112301
EXPERT by FACOM® 6 x 6 point Flare Nut Wrenches - [E112301] EXPERT by FACOM® Flare Nut Wrench 7X9 mm is backordered and will ship as soon as it is back in stock.
Standards and certifications
Standards and certifications
This product complies with the following standards and certifications:
ASME B107.100, DIN 3118, ISO 691
Click here to learn more about the different standards and certifications.
Warranty
Warranty
This product is: This product is covered by the statutory warranty
Click here to learn more about our warranties.
Description
Description
Specifications
Specifications
- FinitionFull Polish
- Longueur du produit139 mm
- Poids net impérial0.09 lbs
- Poids net0 Kg
- Unité de mesureMétrique
Technical drawing and dimensions
Technical drawing and dimensions
| A (mm) | B1 (mm) | B (mm) | C1 (mm) | C (mm) | D1 (mm) | L (mm) | |||
|---|---|---|---|---|---|---|---|---|---|
| E112301 | [E112301] EXPERT by FACOM® Flare Nut Wrench 7X9 mm | 7 | 19.30 | 17.80 | 7.50 | 6.50 | 6.50 | 139.00 | |
| E117368 | [E117368] EXPERT by FACOM® Flare Nut Wrench, 24 x 27 mm | 24 | 46.40 | 42.40 | 17.00 | 16.00 | 20.00 | 255.00 | |
| E117388 | [E117388] EXPERT by FACOM® Flare Nut Wrench 8X10 mm | 8 | 19.30 | 17.80 | 7.50 | 6.50 | 7.00 | 139.00 | |
| E117391 | [E117391] EXPERT by FACOM® 11X13 mm Flare Nut Wrench | 11 | 25.30 | 22.80 | 7.50 | 6.50 | 7.00 | 174.00 | |
| E117392 | [E117392] EXPERT by FACOM® Flare Nut Wrench, 12X14 mm | 12 | 25.30 | 22.80 | 10.50 | 8.50 | 11.00 | 174.00 | |
| E117394 | [E117394] EXPERT by FACOM® Flare Nut Wrench 17X19 mm | 17 | 33.00 | 31.20 | 13.00 | 12.00 | 15.00 | 213.00 | |
| E117395 | [E117395] EXPERT by FACOM® Flare Nut Wrench 19X22 mm | 19 | 38.40 | 33.40 | 38.40 | 33.40 | 17.00 | 228.00 |
